50A Power Supply
The products are full bridge power supplies
Overview
| Image/Model |
|---|
50A24V |
50A64V |
50A40V-Frosted alumi |
50A40V-Stainless ste |
50A30V-Black housing |
| Model | Input Voltage |
Output Voltage |
Output Current |
Output Power |
Number of bars |
Laser Power |
Output current Duty cycle |
Circuit Protection |
Size | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| 50A24V | G--AC 220V/W--AC110V(±10%) | 9.6~24VDC | 10~50A | Maximum 1200W | 5~13 | 250~650W | 26.2V | 217mmx165.48mmx63.2mm | 2.22kg | |
| LD-GL64050 / LD-WL64050 | G--220V / W--110V AC 50Hz(±10%) | 13~64V | 0~50A | Maximum 3200W | 7~32 | 350~1600W | Maximum 30% | Over current protection, temperature protection | 322*183*68mm | 2.7kg |
| LD-GL40050 / LD-WL40050 | G--220V / W--110V AC 50Hz(±10%) | 7.6~40V | 0~50A | Maximum 2000W | 4~20 | 200~1000W | Maximum 40% | Over current protection, temperature protection | 322*183*68mm | 2.7kg |
